Be the first to review “Planewave CDK20 f/7.7 OTA” Cancel reply
Downloads & Manuals
Specifications
Additional information
Design
Telescope Type
Reflector
Optical Design
Newtonian
Mirror Configuration
Primary & Secondary
Optics
Aperture (mm)
150
Focal Length (mm)
600
Focal Ratio (f/-)
4.0
Image Circle (mm)
Not reported
Use Case
Astrophotography
Features
Focuser Type
Dual-Speed Rack-and-Pinion
Focuser Size
2" (50.8mm)
Focuser Position
Side
Coma Corrector
Options Available
Finder
No
Focal Length (mm)
No
Mirror Cooling Fans
No
Dew Shield
No
Collimation Tool
None
Carrying Case
No
Performance
Light Gathering Capacity
x459
Resolving Power (arcsec)
0.77
Stellar Magnitude Limit
13.4
Optimal Magnification Range
25x – 250x
Target Suitability (Visual / Imaging)
Sun
Capable / Well-Suited, Only with Specific Solar Accessories
Moon
Well-Suited / Excellent
Planets
Capable / Capable
Double Stars
Well-Suited / Excellent
Open Clusters
Excellent / Excellent
Globular Clusters
Well-Suited / Well-Suited
Nebulae
Well-Suited / Excellent
Galaxies
Capable / Well-Suited
Comets
Excellent / Excellent
Build
Tube Type
Closed
Tube Material
Carbon Fibre
Primary Mirror Material
Borosilicate Glass
Primary Mirror Shape
Parabolic
Mirror Coating Type
Enhanced Aluminium
Mirror Coating Reflectivity (%)
94
Secondary Mirror
Flat Elliptical
Internal Baffling
Yes
Blackened Interior
Yes
Tube Diameter (mm)
178
Tube Length (Extended, cm)
53
Tube Length (Carrying, cm)
53
Tube Weight (kg)
4.4
Total Weight (kg)
5.2
Value / Ownership
Portability
Good
Ease of Setup
Moderate
Maintenance Requirements
Moderate
Brand Reputation
Well Regarded
Resale Value
Good
